PCIe 5.0 SSDs can advertise roughly twice the sequential throughput of the fastest PCIe 4.0 drives, but that does not mean every PC task becomes twice as fast. The useful question is whether your workload can turn the extra interface bandwidth into time saved.
Quick answer
If you are choosing a drive now, see our Best Internal SSD for a PC guide. You can also add storage alongside the rest of your parts in the Build a PC planner.
PCIe 4.0 vs PCIe 5.0 at a glance
| Feature | PCIe 4.0 NVMe | PCIe 5.0 NVMe |
|---|---|---|
| PCIe signalling rate | 16 GT/s per lane | 32 GT/s per lane |
| Example flagship sequential read | Samsung 990 PRO: up to 7,450 MB/s | Samsung 9100 PRO: up to 14,800 MB/s |
| Best fit | Gaming, Windows, applications and mainstream creation | Heavy transfers and bandwidth-sensitive professional work |
| Platform needs | PCIe 4.0 M.2 slot for full Gen4 performance | PCIe 5.0 M.2 slot for full Gen5 performance |
| Buying priority | Capacity, reliability and value | Workload benefit, cooling and platform support |
What PCIe 5.0 actually doubles
PCI-SIG specifies a 16.0 GT/s per-lane signalling rate for PCIe 4.0 and 32.0 GT/s for PCIe 5.0. That doubling gives SSD controllers substantially more interface bandwidth to work with. It is real technical progress, but interface bandwidth is only one part of storage performance.
SSD behaviour also depends on the controller, NAND, firmware, capacity, queue depth, file size, write cache, thermals and the software issuing the storage requests. A sequential benchmark moving large blocks of data is therefore not the same workload as launching an application or loading thousands of small game assets.
How much faster are current Gen4 and Gen5 drives on paper?
Samsung’s 990 PRO is a useful high-end PCIe 4.0 reference. Samsung rates it at up to 7,450 MB/s sequential read and 6,900 MB/s sequential write. Its newer PCIe 5.0 9100 PRO is rated at up to 14,800 MB/s read and 13,400 MB/s write on the current UK product page.
Those numbers demonstrate the extra headroom very clearly. They do not mean a PC fitted with the Gen5 drive boots, launches every game or completes every task in half the time. Samsung itself notes that performance varies with firmware, system hardware, configuration and other factors.
Do you need PCIe 5.0 for DirectStorage?
No. Microsoft’s current Windows 11 requirements say DirectStorage requires an NVMe SSD using the Standard NVM Express Controller driver and a DirectX 12 GPU with Shader Model 6.0 support. Microsoft does not state that a PCIe 5.0 SSD is required.
This matters because “DirectStorage-ready” and “PCIe 5.0” are not the same buying requirement. A supported PCIe 4.0 NVMe drive can meet Microsoft’s stated storage requirement. Individual games can still behave differently, so game-specific performance should be judged from testing rather than the interface label alone.
Why PCIe 4.0 remains attractive for gaming
Modern high-end Gen4 drives already provide several gigabytes per second of sequential throughput and strong random performance. For a gaming build, it is often more valuable to buy enough SSD capacity for the actual library than to spend a large premium moving from a good 2TB Gen4 drive to a smaller Gen5 model.
This is especially true when the saved budget could improve the graphics card, processor, memory capacity or monitor. A storage upgrade should solve a storage problem rather than simply produce a bigger benchmark number.
When PCIe 5.0 is easier to justify
Gen5 becomes more compelling when you frequently move very large files, use high-speed scratch or project storage, work with large video and media assets, or have another professional workflow that can sustain substantial storage traffic. In those cases, cutting transfer or processing time can have measurable value.
It is also reasonable in a no-compromise high-end build where the motherboard already provides an appropriate Gen5 M.2 slot and cooling, and the cost difference does not force a compromise elsewhere.
Check motherboard lane support before buying
A PCIe 5.0 SSD needs a suitable PCIe 5.0 M.2 connection to reach its full interface capability. Motherboard layouts differ: some boards provide Gen5 for the graphics slot but not every M.2 slot, while using certain storage slots can alter lane allocation elsewhere. Read the motherboard manual rather than assuming every physically compatible M.2 socket has the same bandwidth.
PCIe is designed for backward compatibility, so a newer drive can generally operate in an older-generation compatible slot, but its performance is then constrained by that connection.
Thermals matter more as SSDs get faster
High-performance NVMe drives can reduce performance when they become too hot. Check whether the SSD includes a heatsink, whether the motherboard provides an M.2 heatsink and whether the two are intended to be used together. Small-form-factor PCs deserve particular attention because airflow can be limited.
A cooler, stable drive that sustains its performance is more useful than a peak benchmark result that cannot be maintained in the actual case.
Capacity first, generation second
For most buyers, choose the capacity required for the operating system, applications, games and working files first. A 2TB Gen4 drive may be a better ownership decision than a 1TB Gen5 drive at the same budget if storage pressure would otherwise force constant deletion or an early upgrade.
After capacity, compare current price, warranty, endurance, thermal design and real independent workload testing. Then pay extra for Gen5 if the workload gives you a reason.
Who should choose PCIe 4.0?
- Most gaming-PC builders.
- General Windows and productivity systems.
- Buyers who can get substantially more capacity for the same budget.
- Systems whose motherboard does not provide a suitable Gen5 M.2 slot.
Who should choose PCIe 5.0?
- Professionals frequently moving or processing very large files.
- High-end creators using storage-heavy scratch and project workflows.
- Enthusiasts with a Gen5-capable motherboard, adequate cooling and budget to spare.
- Anyone with measured storage workloads that are actually limited by a high-end Gen4 drive.
Frequently asked questions
Is PCIe 5.0 twice as fast as PCIe 4.0?
The PCIe signalling rate doubles from 16 GT/s to 32 GT/s per lane, and some current SSDs approach roughly twice the headline sequential throughput of high-end Gen4 models. Real application gains depend on the workload and are not automatically 2×.
Do games need a Gen5 SSD?
Not as a general Windows requirement. Microsoft states that DirectStorage requires an NVMe SSD, not specifically a PCIe 5.0 model. Individual games and workloads can still benefit differently from faster storage.
Can I put a PCIe 5.0 SSD in a PCIe 4.0 M.2 slot?
PCIe generations are designed for backward compatibility, so a compatible drive can normally operate at the older link generation. It will not achieve full Gen5 interface performance in a Gen4 slot.
Is 1TB Gen5 better than 2TB Gen4?
Not automatically. If your files and games need more than 1TB, the larger Gen4 drive can be the better practical purchase. Choose capacity first, then pay for additional throughput when your workload can use it.
Primary sources
- PCI-SIG — PCI Express 5.0 FAQ
- Microsoft — Windows 11 feature requirements including DirectStorage
- Samsung UK — 990 PRO PCIe 4.0 specifications
- Samsung UK — 9100 PRO PCIe 5.0 specifications
Final verdict
PCIe 5.0 is genuinely faster, but buy it for a workload rather than the label. A strong Gen4 NVMe SSD remains an excellent fit for most gaming and everyday PCs. Gen5 earns its premium when sustained storage throughput saves meaningful time and the rest of the system can support it properly.
